Product Description

Features and Specifications

1. Housing (Body,Shell)
1) Material: High-pressure Die-cast Aluminium Alloy: RS/SP15-A1B
2) Static Load Capacity: >20T for A1,A1B,A6,A6B and D1;>15T for C1
2. Power Supply
1) Solar Panel (Monocrystalline Silicon):2.5v/0.2w for A1,A1B,A6,A6B,C1,D1
2) Stoarge Battery:
2.1: NI-MH: 1.2v/800mAh,anti-high and anti-low temperature; Lafe Span: >3years
2.2: Super Capacitor:120F; Life Span: >10years
3) Battery Operating Hours:
After full recharge,120 hours for Flashing Mode and 30-40 hours for Constant Mode.
4) Operating Style:Recharging at day-time and working automatically at night
3. LED
1) Diameter: 5mm; double-sided,ultra bright
2) Colors: Red(RD),Yellow(YW),White(WH),Blue(BL),Green(GN)
3) Luminous Mode:
3.1: Flashing (FL) or Constant (CNST) Illumination: RS/SP15-A1,A1B,A6,A6B,C1,D1
3.2: Synchronous (SYNC) Flashing: RS/SP15-C1
4) Luminous Intensity:
5) Visual Distance: >800m
6) Water-proof: IP68
7) Working Temperature: -40~85ºC
4. Other Names
Road Studs are also called "Flashing Spike, Pavement Marker, Cat Eye,or ..."

Model	RS/SP15-A1B-WH
LED Qty.	6pcs (3pcs×2)
Dimensions/PC:(L)×(W)×(H)	108mm×97mm×25mm Anchor Pin Height: 50mm
N.W./PC	354g
Packing Info/Shipping Carton	Qty: 45pcs; G.W.: 19kg; Size: 0.067cbm(64cm×42cm×25cm)

N.B.: Please do indicate the exact Colors and Luminous Modes when you place your Purchase Orders.
*1. Flashing (FL) or Constant (CNST) Illumination: RS/SP15-A1,A1B,A6,A6B,C1,D1
*2. Synchronous (SYNC) Flashing: RS/SP15-C1
*3. Colors: Red(RD),Yellow(YW),White(WH),Blue(BL),Green(GN)
For example,should you wanna order RS/SP15-A1,and you prefer Red(RD) color and Flashing(FL) Illumination, then the final model would RS/SP15-A1-RD/FL, and so on.
